Ultra Compact Design
• FlexRibbons™ are rolled up into compact 288 fiber sub units for easier routing
• Significantly smaller diameter and lighter weight cables allow for easier installation and the use of smaller ducts
• With a 21% smaller diameter (38% volume reduction) over traditional ribbon designs, a 1728 cable can be installed in a 1.25” duct which maximizes duct space utilization
FlexRibbon Technology
• Extremely flexible ribbons can be rolled up for high packing densities or laid flat for ribbon splicing
• 12 fiber ribbons are compatible with mass fusion heat strippers, cleavers, and splice machines
• Uses standard 250 um coated bend-insensitive fiber (ITU G657.A1 or A2)
Performance
• Uses full dry water blocking technology in the tubes and cable core for easy closure preparation and termination
• Tested in accordance with ICEA 640 and with relevant EIA/ TIA-455 series FOTPs for fiber optic cables
